AddOn 10/100/1000Base-TX to 1000Base-LX SMF 1310nm 10km POE Media Converter
Your Price:
$170.31
Item #
N-1028878
Category
Availability
Condition
Brand
Product Rating
(0 Ratings)
Free Shipping
Free Budget Shipping
Many items at NothingButSavings.com offer FREE Budget Shipping. Plus, as with many of our competitors which do offer free shipping, we don't ask you to spend a specified amount in order to qualify for FREE Budget Shipping.
How do I qualify for Free Budget Shipping?
1. Add the item(s) that qualifies for FREE Budget Shipping to your order's shopping cart.
2. If a product has our "Free Shipping" tag that item will qualify for FREE Buget Shipping regardless of its price.
3. Proceed to checkout and select Budget Shipping as your shipping option (items will take an additional 7-10 business days to ship).
4. Ship your item(s) to a valid U.S. address.
5. Then, complete your order. It's that simple!
6. FREE Budget Shipping excludes certain oversized and/or overweight items, and those products that do not include this tag.
Some items may be excluded:
If certain items in your shopping cart are not eligible for Budet Shipping then buedget Shipping will not be available and thus the offer for Free Budget Shipping will not apply.
Free Budget Shipping is not available for International orders.
General Information
| This is a media converter that converts a 10/100/1000Base-TX(RJ-45) to 1000Base-LX(SC) via a 1310nm single-mode fiber (SMF) SC connector, which allows distance reach up to 10km. This provides a cost effective conversion from 10/100/1000Base-TX(RJ-45) to 1000Base-LX fiber, while extending the network reach beyond the 100m reach limitation of copper. This AC/DC powered PoE media converter is a power sourcing equipment (PSE), which combines data transferred over a fiber optic link with 48V (or other voltage) power supply, providing power to IEEE802.3af powered device (PD) over CAT5 and up UTP cable (cable length up to 100 meters / 330 feet). It complies with the IEEE802.3af standard. The converter includes a single port PSE controller, which offers PD signature sensing and power monitoring features. Other features include over-current protection and LFP function. The LFP (Link Fault Pass-through) allows the media converter to monitor both the fiber and copper RX port for loss of signal. In case of a loss of RX signal on one media port, the converter will automatically disable the TX signal to the other media port, thus passing through the link fault. Our media converters are 100% compliant for all of our networking needs. Now you have a cost effective solution to your network upgrade needs. |
Interfaces/Ports
| Total Number of Ports: | 2 |
| Network (RJ-45): | Yes |
| Number of PoE (RJ-45) Ports: | 1 |
| PoE Port Type: | PSE |
| Number of Network (RJ-45) Ports: | 1 |
| Number of SC Ports: | 1 |
Media & Performance
| Media Type Supported: | Optical Fiber |
| Media Type Supported: | Twisted Pair |
| Fiber Mode Supported: | Single-mode |
| Fiber Optic Cable Wavelength: | 1310 nm |
| Maximum Distance Supported: | 10 km |
| Fiber Optic Cable Core/Cladding Specification: | 9/125 µm |
Network & Communication
| Ethernet Technology: | Gigabit Ethernet |
| Network Technology: | 10/100/1000Base-T |
| Network Technology: | 1000Base-LX |
Power Description
| Power Source: | AC |
| Input Voltage: | 120 V AC |
Physical Characteristics
| Height: | 1.5" |
| Width: | 5" |
| Depth: | 6" |
| Weight (Approximate): | 1.40 lb |
Miscellaneous
| Application/Usage: | Network |
| Certifications & Standards: | 802.3af |
| Environmentally Friendly: | Yes |
| Environmental Compliance: | Restriction of Hazardous Substances (RoHS) |
| TAA Compliant: | No |
Warranty
| Limited Warranty: | 3 Year |
 | WARNING: This product can expose you to chemicals including Di(2-ethylhexyl)phthalate (DEHP), which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information, go to www.P65Warnings.ca.gov. |
Product images may differ from actual product appearance.
Be the first to review this product.
Write a Review
Shipping Restrictions
- This item cannot be shipped to PO Boxes.
- This item can be shipped only within the U.S.
- UPC: 821455028216
- Mfr's Part #: ADD-GMCP-LX-1SC
